Professional rotary cultivators
MAK 18 S
Power supply | Engine | Model | Displacement | Power* | Starting | Notes | Code |
---|---|---|---|---|---|---|---|
GX 390 OHV | 389 cm³ | 11.7 HP | recoil start | mono-disc clutch | 68339169E5 | ||
CH 440 OHV | 429 cm³ | 14.0 HP | recoil start/ electric | mono-disc clutch/ battery supplied as standard | 68339159E5 | ||
![]() |
VANGUARD 18 | 570 cm³ | 18.0 HP | recoil start/ electric | mono-disc clutch/ battery supplied as standard | 68339164E5 |
* Engine power data refers to the values declared by each manufacturer. These values are calculated in accordance with specific measurement standards (such as SAE J1940, SAE J1349, ISO 1585) and may be modified without prior notice.
Its characteristics of high power and reliability make this model perfect for farmers and ground care professionals. Combines exceptional ease of handling and versatility with the ability to work on all types of terrain safely, thanks to the self-locking differential and 5-speed gearbox. The powerful engines available for this model are exploited in full thanks to the reinforced half-shafts, while the large size final reduction gears on the axle ensure efficient transmission of the full engine power while increasing the machine’s ground clearance.
- Displacement
- 429 cm³ - 570 cm³
- Gearbox
- 5-speed (4 forward + 1 reverse)
- Transmission
- with gears in oil bath
- Clutch
- dry single disc
- Handlebars
- height- and width-adjustable, 180° reversible, with vibration-damping device
- Reverse gear
- yes, with gearshift lever
- Differential
- yes
- Brakes
- yes
- Power take-off
- 2 power take offs: one indipendent 2-speed PTO (1° 540 rpm - 2° 900 rpm) and one synchronised PTO
- Accessories installation
- flanged to PTO
- Towing hitch
- yes
- Cowling
- yes, with integral tool compartment/battery box
- Weight (with diesel engine, rotor and wheels)
- 230 kg
WITH TWO WHEEL TRACTOR
Gearbox / Speed (km/h):
5-speed (4 forward + 1 reverse) with 6.50/80-12'' wheels
1 | 1.08 |
1R | 2.82 |
2 | 2.02 |
3 | 3.61 |
4 | 7.91 |
Dimensions (mm)

L1 | 2180 |
L2 | 730 |
L3 | 1450 |
H1 | 600-1300 |
W1 | 420-510 |
W2 | 600-900 |
WITH CUTTERBAR MOWER
Gearbox / Speed (km/h):
5-speed (4 forward + 1 reverse) with 6.50/80-12'' wheels
1 | 1.08 |
1R | 2.82 |
2 | 2.02 |
3 | 3.61 |
4 | 7.91 |
Dimensions (mm)

L1 | 2185 |
L2 | 1125 |
L3 | 1060 |
H1 | 700-1300 |
W1 | 450-510 |
W2 | 1150-1600 |
